TPA-200T | Tele-Master

TPA-200T

contact us

FEATURES

．
200W into 25V/70.7V and 4Ω Loads
．
Automated Diagnostic System Test (Push Here Diagnostic®)
．
Four Balanced Mic/Line/Tel Inputs w/ Phantom Power
．
Input Assignable Zone 2 Output
．
Remote Level Control
．
Remote Input Select (RIS)
．
Line Output
．
Preamp In for External Processors
．
Variable Mute Sensitivity Control for Input 1
．
Contact Closure Mute Terminals
．
Optional Rack Mount Kit Available - Model AARMK2-0

SPECIFICATIONS

．
Frequency Response

50Hz - 15kHz
．
Connector Type

4 Position Phoenix 3.5mm Pitch
．
Power Output

Max. Average Power @ 50Hz-15kHz with .5% THD, 4Ω 200W RMS
．
Height

3.66" (93mm)
．
Width

16.54" (420mm)
．
Depth

14.6" (422mm)
．
Weight

26lb
．
Shipping Weight

29.5lb
．
Voltage Compatibility

110V - 120V
